Hebei Shenyi Metal Products Co., Ltd. is one of the leading manufacturers and suppliers of serrated steel grating in China. If you're going to wholesale bulk serrated steel grating made in China, welcome to get free sample from our factory. All customized metal products are with high quality and competitive price.
Benefits of the Product Based on regular flat steel grating, serrated steel grating is created by stamping one side of the load-bearing flat steel bars into a serrated form. It has important benefits due to its distinct structure:
Superior Anti-slip Performance (Core Advantage): In wet, greasy, muddy, or slippery conditions, the serrated pattern offers exceptional traction, successfully preventing people from slipping and cars from skidding. It is the top option for locations with very strict anti-slip regulations.
High Load-Bearing Capacity and High Strength: It can sustain enormous dynamic and static loads within the same span without readily experiencing permanent deformation, maintaining the high load-bearing capacity features of regular steel grating.
Ventilation, Light Transmission, and Drainage: The open mesh design allows rainwater, oil, and debris to drain swiftly, reducing the buildup of water and grime. It also guarantees good air circulation and natural illumination.
Durability: The zinc coating is securely linked to the steel after hot-dip galvanising, which offers remarkable corrosion resistance. With little upkeep, it may endure for more than 20 years in challenging industrial settings and outdoors.
Easy Installation and Economy: Compared to cast iron or other anti-slip materials, standardised and modular manufacture enables on-site installation with just bolts or welding, greatly reducing the construction time and total cost.
Safety Measures
Installation direction is important
To maximise the anti-slip effect, the direction of the serrations must be opposing the direction of pedestrian or vehicle traffic. The anti-slip effect will be significantly diminished if the serrations are parallel to the direction of walking.
01
Risk of high heels becoming stuck
The serrations' depth and spacing might not be appropriate for stiletto heels, such high heels. A lower tooth pitch specification should be used or caution should be used when choosing in business buildings or office places where ladies wearing high heels may regularly pass by.
02
Slightly more challenging to clean
The serrated grooves are more likely to collect fine debris than flat steel grating. strict-pressure water cannons or specialised brushes are needed for cleaning in workplaces with exceptionally strict hygiene standards, such chemical factories and food processing facilities.
03
Protection for handling and cutting
Workers must wear protective gloves during handling and installation since the serrated edges are extremely sharp. If on-site cutting is required, the burrs must be smoothed out and painted with either cold-dip galvanised paint (for galvanised parts) or zinc-rich paint (for ungalvanized parts) to stop rusting along the cut edges.
04
Span and load-bearing capability matching
To prevent the steel grating from bending and deforming as a result of an excessive span, the span must be precisely estimated based on the actual load (such as forklift weight and pedestrian density).
05
Manufacturing Procedure
Purchasing load-bearing flat steel and twisted square/twisted steel (crossbars) that adhere to national requirements is the first step in preparing raw materials.
Levelling and Toothing Flat Steel: Use a levelling machine to level the flat steel.
The main procedure involves feeding the flat steel into a toothing machine, which repeatedly punches regular, consistent serrated forms onto one side of the steel.
Crossbar Cutting: Depending on the customer's desired grid size, cut the twisted square steel to a certain length.
Assembly and Arrangement: Place the crossbars and toothed flat steel at the appropriate intervals, making that the flat steel's serrations are aligned (typically upwards).
Edge banding: To improve overall stiffness and stop edge warping, weld edge banding plates with the same or slightly smaller specifications as the flat steel bars around the steel grating's perimeter.
Pickling to remove rust, flux immersion, and immersion in molten zinc at around 450°C to guarantee a strong connection between the zinc and iron alloy layers are the methods used for surface treatment (mostly hot-dip galvanising).
Finishing and inspection: Check grid size, weld strength, and galvanising quality; remove weld slag; and grind away burrs.
Packing and shipping: For simple forklift loading, unloading and transportation, bundle with steel straps and wooden blocks below.
