Hebei Shenyi Metal Products Co., Ltd. is one of the leading manufacturers and suppliers of outdoor cable ladder in China. If you're going to wholesale bulk outdoor cable ladder made in China, welcome to get free sample from our factory. All customized metal products are with high quality and competitive price.
Product Introduction
Outdoor cable ladders, also referred to as outdoor ladder-type cable trays, are professionally engineered for outdoor cable routing and management. Fabricated from hot-dip galvanized steel, stainless steel or aluminum alloy with durable weatherproof coatings, these cable ladders can withstand long-term exposure to UV rays, rain, snow, extreme temperature changes and various outdoor corrosive environments.
Featuring an open ladder structure, the product delivers superior heat dissipation performance while avoiding water accumulation. It also enables convenient visual inspection of cables, making it a reliable choice for petrochemical plants, power substations, wind farms, solar power stations and all types of outdoor industrial facilities.
Different from ordinary indoor cable trays, our outdoor cable ladders are upgraded with enhanced anti-corrosion performance and higher mechanical strength. With a heavy-duty galvanized layer of no less than 85μm or 316L stainless steel material, they can effectively resist strong wind pressure, ice accumulation and structural deformation caused by thermal expansion and contraction, adapting to harsh outdoor working conditions.
Full Set of Matching Supporting Accessories
To adapt to complex on-site layout requirements and various cable direction changes, our outdoor cable ladder system is equipped with a comprehensive range of supporting accessories. All accessories adopt the same base material and surface treatment process as the main ladder body, ensuring consistent anti-corrosion capability and stable electrical continuity of the entire cable routing system.
|
Accessory |
Function |
|
Horizontal Bend (flat elbow) |
Supports 30°, 45°, 60° and 90° horizontal turning of cable routes, ensuring smooth cable layout without tension and damage. |
|
Vertical Bend (inside/outside elbow) |
Realizes vertical direction adjustment of cables, applicable to scenarios such as climbing along columns and descending to cable trenches. |
|
Three-Way Tee |
Divides a single cable route into two branch routes, perfectly suited for T-shaped wiring junctions on site. |
|
Four-Way Cross |
Forms four-way cable intersections, meeting the wiring needs of complex multi-branch cable distribution centers. |
|
End Cap (terminal cover) |
Seals the open ends of cable ladders, protecting cable insulation layers from damage and avoiding scratches caused by sharp edges. |
|
Connecting Plates & Bolts |
Made of high-strength hot-dip galvanized or stainless steel materials, fixing the connection of ladder sections tightly to form vibration-resistant and stable integral joints. |
|
Cantilever Brackets & Supports |
Available in wall-mounted and floor-standing types, with adjustable height and length, flexible for various installation environments. |
All accessories are pre-punched with standard mounting holes, allowing fast and convenient on-site assembly without special professional tools. The complete system can flexibly realize straight laying, corner turning, branch wiring and vertical drop laying, fully covering all outdoor cable routing demands.
Export-Grade Packaging & Transportation Solutions
Considering that our outdoor cable ladders are mostly transported long-distance and exported overseas, we have formulated strict standardized export packaging procedures to ensure that products remain intact and undamaged from factory delivery to on-site reception.
Stacking & Surface Protection
Straight cable ladder sections are stacked neatly in regular layers. Protective foam sheets, corrugated paper, rubber gaskets and other cushioning materials are placed between every two layers to prevent surface scratches, friction damage and coating abrasion during transportation. Heavy and long-size ladder sections are fixed with nylon straps instead of steel wires, effectively avoiding indentation and damage to the product surface coating.
01
Palletizing Standard
All stacked cable ladders are placed on ISPM-15 certified fumigated solid wood pallets, which fully meet international phytosanitary inspection standards. The pallets are designed with high load-bearing capacity to bear the full static weight of goods, and support four-way forklift and pallet jack handling for convenient loading and unloading.
02
Moisture & Dust Proof Measures
The entire pallet cargo is tightly wrapped with multi-layer UV-resistant stretch film to form a fully sealed waterproof and dustproof protective layer. Meanwhile, corner protectors and edge guards are installed at all sharp corners and edges to prevent the stretch film from being punctured and ensure the integrity of the protective layer.
03
Packaging of Small Accessories
Loose accessories including bolts, nuts, washers, connectors, brackets and end caps are sorted and packed separately in labeled woven bags or small cartons. Each package is clearly marked with accessory names, specifications and quantities to avoid confusion. All small accessory packages are uniformly fixed on the same pallet or integrated into export cartons to prevent loss during transit.
04
Labeling & Complete Shipping Documents
The outer surface of each package is affixed with clear marks, including product specifications (e.g., 600×150×2.0mm, hot-dip galvanized), gross weight, net weight, country of origin, project name and order number, as well as standard handling labels such as "Fragile", "Keep Dry" and "This Side Up".
05
Each batch of shipment is accompanied by complete official documents, including Certificate of Conformity, professional quality inspection reports (covering coating thickness detection, adhesion test and dimensional inspection) and detailed pallet/carton-based packing lists.
Advantages of Our Outdoor Cable Ladder System
One-stop full solution: Complete matching products from main ladder bodies to all supporting accessories, realizing one-time procurement and simplifying project procurement management.
Professional export packaging: Strict export-grade packaging effectively avoids product damage during long-distance transportation and reduces project material loss.
Traceable guaranteed quality: Complete inspection documents and shipping materials support smooth customs clearance and on-site project acceptance.
Long outdoor service life: Targeted anti-corrosion and weather-resistant design ensures stable performance for more than 20 years in outdoor harsh environments.
With our complete accessory system and standardized export packaging services, your outdoor cable ladder laying projects can achieve seamless docking from factory delivery to on-site installation, ensuring smooth project progress.
