Hebei Shenyi Metal Products Co., Ltd. is one of the leading manufacturers and suppliers of tank entanglement net in China. If you're going to wholesale bulk tank entanglement net made in China, welcome to get free sample from our factory. All customized metal products are with high quality and competitive price.
Technical specifications and parameters
|
Specification item |
Typical parameters and options |
|
Network cable diameter |
0.5 mm, 0.6 mm, 0.8 mm, 0.9 mm |
|
mesh size |
About 25-50 cm |
|
Type A net (wave net) |
After unfolding, it measures approximately 10 meters in length, 4 meters in width, and 0.4 meters in height, making it suitable for laying on large areas of ground or grass |
|
Type B net (wheel/roll net) |
The monomer is composed of 10-20 cylindrical net rolls stacked together; when unfolded, the overall coverage area can reach 10x10x1.4 meters, or even larger |
|
folded dimensions |
When folded, a single net roll measures approximately 1.2 x 0.6 x 0.12 to 0.8 meters, making it easy to transport and store |
|
Single set weight |
The main packaging should not exceed 24-30 kilograms |
|
MZP package configuration |
In addition to the netting, a set of MZP (Russian military obstacle) packaging typically includes 40 fixing rings and stakes |
|
surface treatment |
It is usually galvanized, but also has a black coating. Some designs can be equipped with barbs or sharp blades |
Core materials
The tank entanglement net is primarily constructed from high-strength, corrosion-resistant metallic materials, laying the foundation for its effectiveness and durability.
Common materials:
The most common material is galvanized steel wire. To enhance corrosion resistance, stainless steel is also used, with common types including 304, 316, and 316L.
Wire types:
The supplier offers a variety of wires, such as carbon steel wire, black iron wire, or galvanized iron wire, to meet the needs of different costs and application environments.
Production process
Its production process mainly includes automated steps such as material selection and weaving molding, which is efficient and customizable.
Raw material preparation: Purchase high-strength, corrosion-resistant metal wires (such as galvanized steel wire, stainless steel wire) that meet the requirements.
Braiding: The process of weaving wire materials into a specific structure using precision machinery. The main technique employed is plain weave. Additionally, there are other specific processes such as "weaving and winding".
Roll formation (wheel-type net): Roll the woven net separately into a single cylindrical net roll (garland).
Assembly components: Some products also come with a fixing ring and a pile (such as the MZP set).
Quality inspection and warehousing: All finished products must undergo rigorous performance testing, including tensile strength and corrosion resistance.
Usage scenarios
Its application scenarios are extensive, mainly falling into the following two categories:
1. Armored vehicle and tank protection
It is installed on the tank body or gun barrel in a cage-like or covering manner.
Working principle: It detonates incoming anti-tank rockets and interferes with magnetic mines in advance.
Application scenario: installed on the exterior of tank turrets and vehicle bodies.
2. Battlefield stagnation and border blockade
Lay it on key terrain in the form of large-area coverage or net barriers.
Working principle: It engages with the tank/vehicle's propulsion system and becomes entangled, causing it to become blocked and unable to move.
Application Scenario:
Military strongholds and border blockades: defending important positions or national borders.
Block and delay the enemy's armored vehicle convoy: disrupt the enemy's offensive rhythm.
Asymmetric and anti-drone warfare: It has also been attempted as a low-cost solution for anti-drone nets in some conflicts.
Protection of critical infrastructure: Defend nodes such as bridges and power stations.
Rapid deployment in special terrains: Quickly block various terrains such as roads, swamps, and rooftops of buildings.
